Description

Overview section structure

• 2 points lock system
• Can have two different colors inside and outside
• Has good heat insulation properties

Widely used

• Balcony, sunroom, room partitions, conference room, banquet hall

Hardware configuration

• SI Aubi brand

Glass configuration

• 5mm (clear) + 6A + 5mm (clear) Hollow double tempered

Specifications configuration

• Aluminum alloy profile thickness 1.4mm

Technical parameters

Indicator Name	Detection Value	National Standard No.
Anti-wind pressure performance	Level 6 (highest is 9)	GB/T8478-2008
Air tight performance	Level 5 (highest is 8)	GB/T8478-2008
Water tight performance	Level 5 (highest is 6)	GB/T8478-2008
Sound insulation performance	Level 4 (highest is 6)	GB/T8478-2008

---
