Description

Overview section structure

• European standard design, beautiful and exquisite, no external leakage machining hole
• A wide range of combination styles, a variety of models you can choose, three cavity profile structure, multi-cavity with high sound insulation, high energy saving effect
• Anti-theft performance, use chain (hinge) form to open, multiple lock point structure to achieve the best anti-theft performance
• Sealing performance: sealing strip adopts three-EPDM soft and hard coextrusion method, less opening and closing force, higher sealing performance
• Anti-mosquito performance: stainless steel flyscreen integrated in windows

Widely used

• Exterior wall windows for buildings

Hardware configuration

• German brand Siegenia, GU

Glass configuration

• 6mm (clear) + 12A + 6mm (clear) Hollow double tempered

Specifications configuration

• Aluminum alloy profile thickness 1.5 mm



Technical parameters

Indicator Name	Detection Value	National Standard No.
Anti-wind pressure performance	Level 7 (highest is 9)	GB/T8478-2008
Air tight performance	Level 6 (highest is 8)	GB/T8478-2008
Water tight performance	Level 5 (highest is 6)	GB/T8478-2008
Sound insulation performance	Level 4 (highest is 6)	GB/T8478-2008
